JBL SRX828S

系统类型 Passive dual 18”, subwoofer system

Maximum SPL Output 129dB (Continuous), 135dB (Peak)

频率范围 (-10dB) 30hz - 150hz

Frequency Response (-3 dB) 47Hz - 120Hz

灵敏度 98dB

系统额定功率 4800W Peak, 2400W Program, 1200W Continuous

标称阻抗 4 Ohm

输入通道 NL4 Input, NL4 Loop-thru (+/-1 or +/-2 Selectable)

Operational Modes Passive

低频驱动单元 (2x) 2279H

分频点 80hz

Enclosure 18mm Duraflex coated plywood

Casters Accepts JBL WK-4S Kit

Handles 8

外观颜色 Obsidian Duraflex™ finish

网罩 Powder coated, Obsidian, 14-gauge perforated steel with acoustically transparent black cloth backing

尺寸（高 x 宽 x 厚） 681mm x 1205mm x 574mm (26.79in x 47.42in x 22.57in)

重量 137.0 lbs (62.1g)

运输重量 147.0 (66.5kg)
