JBL SRX835SP

系统类型 Self powered 15”, three-way, bass-reflex

Maximum SPL (1m) 137 dB

频率范围 (-10dB) 33 Hz - 21 kHz

Frequency Response (±3 dB) 41 Hz - 20 kHz

覆盖范围 60° x 40°

Amplifier Design Class D

额定功率 2000 W Peak

尺寸（高 x 宽 x 厚） 476mm x 544mm x 984mm (18.74in x 21.4in x 38.74in)

Net Weight (each) 38.6 kg (85 lb)

EQ 20 parametric EQ's, speaker delay, and 50 available slots for presets

输入通道 Neutrik ¼ - XLR input; Neutrik XLR Output

输出 2 x XLR

Enclosure 18 mm, 11-ply Finnish birch plywood; black DuraFlex™ finish; integral recessed handles

标称阻抗 NA - amplification is integrated

低频驱动单元 1 x 2275F, Differential Drive®, 15" diameter

MF Driver 1 x 2107H

HF 驱动程序 1 x 2432H compression driver, neodymium 76mm (3 in) diameter voice coil

Suspension / Mounting Single 36 mm pole socket, 12 x M10 suspension points
